5 Inch Display for Raspberry Pi

A compact 5-inch HDMI display with 5-point capacitive touchscreen—perfect for portable Raspberry Pi projects, embedded systems, and custom interfaces. The 800×480 resolution delivers clear visuals, while the built-in speaker and headphone jack provide audio flexibility.

Plug-and-play operation with no drivers required. Compatible with Raspberry Pi, Jetson Nano, BeagleBone, and any device with HDMI output. Mounting holes and nut seats on the back make installation easy.

Key Features

• 5-Inch TFT Display – 800×480 resolution with 300cd/m² brightness
• 5-Point Capacitive Touch – Smooth, accurate multi-touch input via USB
• Built-in Audio – Speaker interface and 3.5mm headphone jack
• Plug-and-Play – No driver installation required
• Pi Mounting Points – 4 nut seats for Raspberry Pi attachment
• Multi-System Compatible – Works with Raspbian, Ubuntu, Windows, Android, macOS, Chrome OS

Specifications

• Screen Size: 5.0 inch
• Resolution: 800 × 480
• Panel Type: TN TFT-LCD
• Brightness: 300cd/m²
• Touch: 5-point capacitive (ILI6122 & ILI5960)
• Power: DC 5V 2A
• Active Area: 108 × 65mm
• Module Size: 137 × 80 × 14mm
• Weight: 140g

Ideal For

• Raspberry Pi portable projects
• Embedded system interfaces
• Kiosk and information displays
• DIY tablets and consoles
• Jetson Nano and BeagleBone projects

Package Contents

• 1× 5-Inch HDMI Display
• 1× HDMI Cable
• 1× USB-A to Type-C Cable
• 1× HDMI to Mini HDMI Adapter
• 1× User Manual

Resources

• User Manual (PDF)
• Elecrow Wiki
