Pi Zero ENC28j60 Network Adapter Module for Raspberry Pi Zero

Add wired Ethernet connectivity to your Raspberry Pi Zero with this compact ENC28J60 network adapter module. Connects directly to the GPIO header and provides reliable 10Mbps Ethernet for system updates, software installation, and network access.

Key Features

• Wired Ethernet – 10Mbps network connectivity via RJ45
• GPIO Connection – Plugs directly into Pi Zero header
• Compact Design – Sized for Pi Zero form factor
• Easy Setup – Single line in config.txt to enable

Setup Instructions

1. Install the module onto Raspberry Pi Zero GPIO header
2. Connect Ethernet cable to router (DHCP required)
3. Edit /boot/config.txt and add: dtoverlay=enc28j60
4. Save and reboot
5. Verify with ifconfig command

Specifications

• Chip: ENC28J60
• Speed: 10Mbps
• Compatibility: Raspberry Pi Zero, Pi Zero W
• Dimensions: 65 × 30 mm
• Weight: 19g

Package Contents

• 1× ENC28J60 Network Adapter Module
